Home / Lenses / Telecentric lenses / 0.303× telecentric lens, 1.1", C-Mount

0.303× telecentric lens, 1.1", C-Mount (LS-TCL-0380)

Rendered illustration: the actual product may differ in appearance.

Telecentric lenses

0.303× telecentric lens, 1.1", C-Mount (LS-TCL-0380)

Model LS-TCL-0380

0.303× telecentric lens, 1.1", C-Mount. Working distance 132.9 mm. Depth of field 4.5 mm.

Datasheet (PDF) - LS-TCL-0380 3D model (STEP) - LS-TCL-0380

Specifications

Model	LS-TCL-0380
Depth Of Field	4.5 mm
Distortion Maximum (%)	< 0.1
Distortion Typical (%)	< 0.08
Filter Thread	No Filter Threads
FoV @ 1/2.0″	37.46 x 23.53 mm
FoV @ 1″	46.83 x 24.79 mm
Fov @ 1.1″	46.73 x 34.22 mm
Image Circle Diameter	17.6 mm
Image Size Dimensions	15.29 x 15.29 mm
Imager Format	1.1"
Lens Type	Telecentric
Magnification	0.303×
Mount	C-Mount
Resolution (Pixel Size)	17 μm
Telecentricity Maximum	0.10°
Telecentricity Typical	< 0.08°
Working Distance	132.9 mm
Working ƒ/N	f/8
