Home / Lenses / Telecentric lenses / 0.087× telecentric lens, 1/1.2", C-Mount

0.087× telecentric lens, 1/1.2", C-Mount (LS-TCL-0370)

Rendered illustration: the actual product may differ in appearance.

Telecentric lenses

0.087× telecentric lens, 1/1.2", C-Mount (LS-TCL-0370)

Model LS-TCL-0370

0.087× telecentric lens, 1/1.2", C-Mount. Working distance 334.6 mm. Depth of field 54.7 mm.

Datasheet (PDF) - LS-TCL-0370 3D model (STEP) - LS-TCL-0370

Specifications

Model	LS-TCL-0370
Depth Of Field	54.7 mm
Distortion Maximum (%)	< 0.1
Distortion Typical (%)	< 0.08
Filter Thread	No Filter Threads
FoV @ 1/1.8″	81.95 x 61.26 mm
FoV @ 2/3″	97.70 x 81.49 mm
Fov @ 1.2″	130.46 x 81.95 mm
Image Circle Diameter	13.5 mm
Image Size Dimensions	11.1 x 11.1 mm
Imager Format	1/1.2"
Lens Type	Telecentric
Magnification	0.087×
Mount	C-Mount
Resolution (Pixel Size)	58 μm
Telecentricity Maximum	0.10°
Telecentricity Typical	< 0.08°
Working Distance	334.6 mm
Working ƒ/N	f/8
