Home / Lenses / Telecentric lenses / 0.222× telecentric lens, 1/1.2", C-Mount

0.222× telecentric lens, 1/1.2", C-Mount (LS-TCL-0365)

Rendered illustration: the actual product may differ in appearance.

Telecentric lenses

0.222× telecentric lens, 1/1.2", C-Mount (LS-TCL-0365)

Model LS-TCL-0365

0.222× telecentric lens, 1/1.2", C-Mount. Working distance 132.4 mm. Depth of field 8.4 mm.

3D model (STEP) - LS-TCL-0365

Specifications

Model	LS-TCL-0365
Depth Of Field	8.4 mm
Distortion Maximum (%)	< 0.1
Distortion Typical (%)	< 0.08
Filter Thread	No Filter Threads
FoV @ 1/1.8″	32.12 x 24.01 mm
FoV @ 2/3″	38.29 x 31.94 mm
Fov @ 1.2″	51.13 x 32.12 mm
Image Circle Diameter	13.3 mm
Image Size Dimensions	11.6 x 11.6 mm
Imager Format	1/1.2"
Lens Type	Telecentric
Magnification	0.222×
Mount	C-Mount
Resolution (Pixel Size)	23 μm
Telecentricity Maximum	0.10°
Telecentricity Typical	< 0.08°
Working Distance	132.4 mm
Working ƒ/N	f/8

Complete the station

The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.
