Rendered illustration: the actual product may differ in appearance.
Telecentric lenses
0.114× telecentric lens, 1/2", C-mount (LS-TCL-0360)
Model LS-TCL-0360
Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Working distance 157.8 mm; depth of field 31.9 mm.
Specifications
| Model | LS-TCL-0360 |
|---|---|
| Magnification | 0.114× |
| Working distance | 157.8 mm |
| Sensor format | 1/2" |
| Mount | C-Mount |
| Depth of field | 31.9 mm |
| Dimensions approximate | 121 x 110 x 94 mm |
| Distortion maximum (%) | < 0.1 |
| Distortion typical (%) | < 0.04 |
| Filter thread | No Filter Threads |
| Fov @ 1/1.8″ | 62.54 x 46.75 mm |
| Fov @ 1/2.0″ | 56.14 x 42.11 mm |
| Fov @ 1/2.5″ | 50.00 x 37.54 mm |
| Fov @ 1/2″ | 56.14 x 42.11 mm |
| Fov @ 1/3.0″ | 42.11 x 31.58 mm |
| Fov @ 2/3″ | 62.19 mm ø |
| Image circle | 8.1 mm |
| Image size dimensions | 7.1 x 7.1 mm |
| Lens type | Telecentric |
| Operating temperature range | 0 to 40°C |
| Resolution (pixel size) | 45 μm |
| Storage temperature range | 0 to 50°C |
| Telecentricity maximum | 0.08° |
| Telecentricity typical | < 0.04° |
| Working ƒ/n | f/8 |
| Weight | 1531 Grams |
