Rendered illustration: the actual product may differ in appearance.
Telecentric lenses
0.134× telecentric lens, 1/2", C-mount (LS-TCL-0359)
Model LS-TCL-0359
Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Working distance 132.9 mm; depth of field 23.1 mm.
Specifications
| Model | LS-TCL-0359 |
|---|---|
| Magnification | 0.134× |
| Working distance | 132.9 mm |
| Sensor format | 1/2" |
| Mount | C-Mount |
| Depth of field | 23.1 mm |
| Dimensions approximate | 111 x 106 x 77 mm |
| Distortion maximum (%) | < 0.1 |
| Distortion typical (%) | < 0.06 |
| Filter thread | No Filter Threads |
| Fov @ 1/1.8″ | 52.91 mm ø |
| Fov @ 1/2.0″ | 53.21 x 39.78 mm |
| Fov @ 1/2.5″ | 47.76 x 35.82 mm |
| Fov @ 1/2″ | 53.21 x 39.78 mm |
| Fov @ 1/3.0″ | 35.82 x 26.87 mm |
| Fov @ 2/3″ | 52.91 mm ø |
| Image circle | 8 mm |
| Image size dimensions | 7.1 x 7.1 mm |
| Lens type | Telecentric |
| Operating temperature range | 0 to 40°C |
| Resolution (pixel size) | 38 μm |
| Storage temperature range | 0 to 50°C |
| Telecentricity maximum | 0.10° |
| Telecentricity typical | < 0.07° |
| Working ƒ/n | f/8 |
| Weight | 1096 Grams |
