Rendered illustration: the actual product may differ in appearance.
Telecentric lenses
0.088× telecentric lens, 4/3", F-mount (LS-TCL-0357)
Model LS-TCL-0357
Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Working distance 288 mm; depth of field 81.1 mm.
Specifications
| Model | LS-TCL-0357 |
|---|---|
| Magnification | 0.088× |
| Working distance | 288 mm |
| Sensor format | 4/3" |
| Mount | F-Mount |
| Depth of field | 81.1 mm |
| Dimensions approximate | 373 x 344 x 410 mm |
| Distortion maximum (%) | < 0.8 |
| Distortion typical (%) | < 0.8 |
| Filter thread | No Filter Threads |
| Fov @ 1.1″ | 161.83 x 118.51 mm |
| Fov @ 1.2″ | 129.71 x 81.49 mm |
| Fov @ 1.3″ | 164.57 x 164.57 mm |
| Fov @ 1″ | 162.17 x 85.83 mm |
| Fov @ 4/3″ | 200 x 121.26 |
| Image size dimensions | 19.82 x 14.88 mm |
| Lens type | Telecentric |
| Operating temperature range | 0 to 40°C |
| Residual distortion (%) | < 0.01 |
| Resolution (pixel size) | 87 μm |
| Storage temperature range | 0 to 50°C |
| Telecentricity maximum | 0.18° |
| Telecentricity typical | < 0.12° |
| Working ƒ/n | f/12 |
| Weight | 9195 Grams |
