Home / Lenses / Telecentric lenses / 0.053× telecentric lens, 1.1", C-Mount

0.053× telecentric lens, 1.1", C-Mount (LS-TCL-0355)

Rendered illustration: the actual product may differ in appearance.

Telecentric lenses

0.053× telecentric lens, 1.1", C-Mount (LS-TCL-0355)

Model LS-TCL-0355

0.053× telecentric lens, 1.1", C-Mount. Working distance 366 mm. Depth of field 184.2 mm.

Datasheet (PDF) - LS-TCL-0355 3D model (STEP) - LS-TCL-0355

Specifications

Model	LS-TCL-0355
Depth Of Field	184.2 mm
Distortion Maximum (%)	< 0.9
Distortion Typical (%)	< 0.9
Filter Thread	No Filter Threads
FoV @ 1″	267.74 x 141.7 mm
Fov @ 1.1″	267.17 x 195.66 mm
Fov @ 1.2″	214.15 x 134.53 mm
Image Size Dimensions	14.9 x 10.9 mm
Imager Format	1.1"
Lens Type	Telecentric
Magnification	0.053×
Mount	C-Mount
Resolution (Pixel Size)	120 μm
Telecentricity Maximum	0.22°
Telecentricity Typical	< 0.18°
Working Distance	366 mm
Working ƒ/N	f/10
