Rendered illustration: the actual product may differ in appearance.
Telecentric lenses
0.064× telecentric lens, 1.1", C-mount (LS-TCL-0354)
Model LS-TCL-0354
Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Working distance 288 mm; depth of field 125.9 mm.
Specifications
| Model | LS-TCL-0354 |
|---|---|
| Magnification | 0.064× |
| Working distance | 288 mm |
| Sensor format | 1.1" |
| Mount | C-Mount |
| Depth of field | 125.9 mm |
| Dimensions approximate | 371 x 344 x 410 mm |
| Distortion maximum (%) | < 0.8 |
| Distortion typical (%) | < 0.8 |
| Filter thread | No Filter Threads |
| Fov @ 1.1″ | 200 x 161.78 mm |
| Fov @ 1.2″ | 177.07 x 111.23 mm |
| Fov @ 1″ | 200 x 117.16 mm |
| Image size dimensions | 14.9 x 10.9 mm |
| Lens type | Telecentric |
| Operating temperature range | 0 to 40°C |
| Residual distortion (%) | < 0.01 |
| Resolution (pixel size) | 99 μm |
| Storage temperature range | 0 to 50°C |
| Telecentricity maximum | 0.18° |
| Telecentricity typical | < 0.12° |
| Working ƒ/n | f/10 |
| Weight | 9053 Grams |
Complete the station
The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.
