Rendered illustration: the actual product may differ in appearance.
Telecentric lenses
0.086× telecentric lens, 1.1", C-mount (LS-TCL-0353)
Model LS-TCL-0353
Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Working distance 232 mm; depth of field 77.3 mm.
Specifications
| Model | LS-TCL-0353 |
|---|---|
| Magnification | 0.086× |
| Working distance | 232 mm |
| Sensor format | 1.1" |
| Mount | C-Mount |
| Depth of field | 77.3 mm |
| Dimensions approximate | 340 x 303 x 332 mm |
| Distortion maximum (%) | < 0.8 |
| Distortion typical (%) | < 0.8 |
| Filter thread | No Filter Threads |
| Fov @ 1.1″ | 165.03 x 120.86 mm |
| Fov @ 1.2″ | 132.28 x 83.1 mm |
| Fov @ 1″ | 165.38 x 87.53 mm |
| Image size dimensions | 14.9 x 10.9 mm |
| Lens type | Telecentric |
| Operating temperature range | 0 to 40°C |
| Residual distortion (%) | < 0.01 |
| Resolution (pixel size) | 81 μm |
| Storage temperature range | 0 to 50°C |
| Telecentricity maximum | 0.10° |
| Telecentricity typical | < 0.06° |
| Working ƒ/n | f/11 |
| Weight | 7301 Grams |
