Rendered illustration: the actual product may differ in appearance.
Telecentric lenses
0.036× telecentric lens, 2/3", C-mount (LS-TCL-0352)
Model LS-TCL-0352
Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Working distance 366 mm; depth of field 319.4 mm.
Specifications
| Model | LS-TCL-0352 |
|---|---|
| Magnification | 0.036× |
| Working distance | 366 mm |
| Sensor format | 2/3" |
| Mount | C-Mount |
| Depth of field | 319.4 mm |
| Dimensions approximate | 435 x 397 x 480 mm |
| Distortion maximum (%) | < 0.9 |
| Distortion typical (%) | < 0.9 |
| Filter thread | No Filter Threads |
| Fov @ 1/1.8″ | 198.06 x 148.06 mm |
| Fov @ 1/2.0″ | 177.78 x 133.33 mm |
| Fov @ 1/2.5″ | 158.33 x 118.89 mm |
| Fov @ 1/2″ | 177.78 x 133.33 mm |
| Fov @ 1/3.0″ | 133.33 x 100.00 mm |
| Fov @ 2/3″ | 236.11 x 196.94 mm |
| Image size dimensions | 8.93 x 7.45 mm |
| Lens type | Telecentric |
| Operating temperature range | 0 to 40°C |
| Residual distortion (%) | < 0.01 |
| Resolution (pixel size) | 141 μm |
| Storage temperature range | 0 to 50°C |
| Telecentricity maximum | 0.22° |
| Telecentricity typical | < 0.18° |
| Working ƒ/n | f/8 |
| Weight | 12337 Grams |
