Home / Lenses / Telecentric lenses / 0.044× telecentric lens, 2/3", C-Mount

0.044× telecentric lens, 2/3", C-Mount (LS-TCL-0351)

Rendered illustration: the actual product may differ in appearance.

Telecentric lenses

0.044× telecentric lens, 2/3", C-Mount (LS-TCL-0351)

Model LS-TCL-0351

0.044× telecentric lens, 2/3", C-Mount. Working distance 328 mm. Depth of field 215.8 mm.

Datasheet (PDF) - LS-TCL-0351 3D model (STEP) - LS-TCL-0351

Specifications

Model	LS-TCL-0351
Depth Of Field	215.8 mm
Distortion Maximum (%)	< 0.8
Distortion Typical (%)	< 0.8
Filter Thread	No Filter Threads
FoV @ 1/1.8″	162.79 x 121.69 mm
FoV @ 1/2.0″	146.12 x 109.59 mm
FoV @ 1/2.5″	130.14 x 97.72 mm
FoV @ 1/3.0″	109.59 x 82.19 mm
FoV @ 2/3″	194.06 x 161.87 mm
Image Size Dimensions	8.93 x 7.45 mm
Imager Format	2/3"
Lens Type	Telecentric
Magnification	0.044×
Mount	C-Mount
Resolution (Pixel Size)	115.9 μm
Telecentricity Maximum	0.18°
Telecentricity Typical	< 0.12°
Working Distance	328 mm
Working ƒ/N	f/8

Complete the station

The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.
