Rendered illustration: the actual product may differ in appearance.
Telecentric lenses
0.033× telecentric lens, 1/1.8", C-mount (LS-TCL-0348)
Model LS-TCL-0348
Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Working distance 328 mm; depth of field 382.5 mm.
Specifications
| Model | LS-TCL-0348 |
|---|---|
| Magnification | 0.033× |
| Working distance | 328 mm |
| Sensor format | 1/1.8" |
| Mount | C-Mount |
| Depth of field | 382.5 mm |
| Dimensions approximate | 358 x 344 x 410 mm |
| Distortion maximum (%) | < 0.8 |
| Distortion typical (%) | < 0.8 |
| Filter thread | No Filter Threads |
| Fov @ 1/1.8″ | 200 x 162.01 mm |
| Fov @ 1/2.0″ | 194.53 x 145.90 mm |
| Fov @ 1/2.5″ | 173.25 x 130.09 mm |
| Fov @ 1/2″ | 194.53 x 145.90 mm |
| Fov @ 1/3.0″ | 145.90 x 109.42 mm |
| Image size dimensions | 7.48 x 5.6 mm |
| Lens type | Telecentric |
| Operating temperature range | 0 to 40°C |
| Residual distortion (%) | < 0.01 |
| Resolution (pixel size) | 154.3 μm |
| Storage temperature range | 0 to 50°C |
| Telecentricity maximum | 0.18° |
| Telecentricity typical | < 0.12° |
| Working ƒ/n | f/8 |
| Weight | 8897 Grams |
