Rendered illustration: the actual product may differ in appearance.
Telecentric lenses
0.159× telecentric lens, 4K, M42-mount (LS-TCL-0289)
Model LS-TCL-0289
Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Working distance 254 mm; depth of field 66.5 mm.
Specifications
| Model | LS-TCL-0289 |
|---|---|
| Magnification | 0.159× |
| Working distance | 254 mm |
| Sensor format | 4K |
| Mount | M42-Mount |
| Depth of field | 66.5 mm |
| Dimensions approximate | 522.4 x 208 x 54 mm |
| Distortion maximum (%) | < 0.1 |
| Distortion typical (%) | < 0.08 |
| Filter thread | No Filter Threads |
| Image circle | 28.7 mm |
| Lens type | Telecentric |
| Line 2k-5µm | 90.19 mm |
| Line 2k-7µm | 128.81 mm |
| Line 4k-5µm | 180.31 mm |
| Line 4k-7µm | 64.4 mm |
| Operating temperature range | 0 to 40°C |
| Resolution (pixel size) | 64 μm |
| Storage temperature range | 0 to 50°C |
| Telecentricity maximum | 0.10° |
| Telecentricity typical | < 0.08° |
| Working ƒ/n | f/16 |
| Weight | 3440 Grams |
