Rendered illustration: the actual product may differ in appearance.
Telecentric lenses
0.319× telecentric lens, 4K, M42-mount (LS-TCL-0284)
Model LS-TCL-0284
Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Working distance 174 mm; depth of field 16.5 mm.
Specifications
| Model | LS-TCL-0284 |
|---|---|
| Magnification | 0.319× |
| Working distance | 174 mm |
| Sensor format | 4K |
| Mount | M42-Mount |
| Depth of field | 16.5 mm |
| Dimensions approximate | 395.2 x 114 x 52 mm |
| Distortion maximum (%) | < 0.08 |
| Distortion typical (%) | < 0.05 |
| Filter thread | No Filter Threads |
| Image circle | 28.7 mm |
| Lens type | Telecentric |
| Line 2k-5µm | 44.95 mm |
| Line 2k-7µm | 64.2 mm |
| Line 4k-5µm | 89.87 mm |
| Line 4k-7µm | 32.1 mm |
| Operating temperature range | 0 to 40°C |
| Resolution (pixel size) | 32 μm |
| Storage temperature range | 0 to 50°C |
| Telecentricity maximum | 0.10° |
| Telecentricity typical | < 0.05° |
| Working ƒ/n | f/16 |
| Weight | 1702 Grams |
