Rendered illustration: the actual product may differ in appearance.
Telecentric lenses
0.187× telecentric lens, 35mm Full Frame, F-mount (LS-TCL-0214)
Model LS-TCL-0214
Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Working distance 457.5 mm; depth of field 37.7 mm.
Specifications
| Model | LS-TCL-0214 |
|---|---|
| Magnification | 0.187× |
| Working distance | 457.5 mm |
| Sensor format | 35mm Full Frame |
| Mount | F-Mount |
| Depth of field | 37.7 mm |
| Aps-c IMX342 | 119.57 x 89.68 mm |
| CHR70M | 165.78 x 117.6 mm |
| CMV50000 | 194.82 x 147.69 mm |
| Dimensions approximate | 741.6 x 260 x 260 mm |
| Distortion maximum (%) | < 0.1 |
| Distortion typical (%) | < 0.05 |
| Filter thread | No Filter Threads |
| Fov @ full frame | 192.51 x 128.34 mm |
| Front diameter | 260 mm |
| Image circle | 43.3 mm |
| Lens type | Telecentric |
| Line 8k-5µm | 218.18 mm |
| Operating temperature range | 0 to 40°C |
| Resolution (pixel size) | 54 μm |
| Storage temperature range | 0 to 50°C |
| Telecentricity maximum | 0.08° |
| Telecentricity typical | < 0.06° |
| Working ƒ/n | f/16 |
| Weight | 10257 Grams |
