0.184× telecentric lens, APS-C, F-mount (LS-TCL-0126)
Model LS-TCL-0126
Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error.
Specifications
| Model | LS-TCL-0126 |
|---|---|
| Mount | F-mount |
| 4/3″ IMX367 | 83.1 x 83.15 mm |
| 4/3″ IMX387 | 102.55 x 57.83 mm |
| Aps-c IMX342 | 121.52 x 91.14 mm |
| Clear aperture | Ø166 |
| Dimensions (dia. x length, mm) | 180 x 442.42 |
| Dimensions approximate | 442.4 x 180 x 180 mm |
| Distortion maximum (%) | < 0.1 |
| Distortion typical (%) | < 0.06 |
| Flange distance | 46.5 mm (F-mount) |
| Front clamping diameter | Ø180 h8 |
| Front diameter | 180 mm |
| Front flange holes | M5 x4 and Ø8 x4 on Ø165 circle |
| Image circle | 28 mm |
| Lens type | Telecentric |
| Line 4k-7µm | 155.82 mm |
| Operating temperature range | 0 to 40°C |
| Other diameters | Ø180 h8 (second clamping/flange), Ø100 (rear cone start), Ø37.80 h8 (rear clamping), Ø45, Ø64 (mount ring) |
| Phase adjustment | yes |
| Rear protrusion behind mount | 4.3 mm |
| Resolution (pixel size) | 28 μm |
| Storage temperature range | 0 to 50°C |
| Telecentricity maximum | 0.10° |
| Telecentricity typical | < 0.07° |
| Working ƒ/n | f/8 |
| Weight (g) | 4884 |
