Rendered illustration: the actual product may differ in appearance.
Telecentric lenses
1× telecentric lens, 2/3", C-mount (LS-TCL-0071)
Model LS-TCL-0071
Telecentric lens with constant magnification across the depth of field, for measurement and gauging without perspective error. Working distance 110 mm; depth of field 1 mm.
Specifications
| Model | LS-TCL-0071 |
|---|---|
| Magnification | 1× |
| Working distance | 110 mm |
| Sensor format | 2/3" |
| Mount | C-Mount |
| Depth of field | 1 mm |
| Dimensions approximate | 125.5 x 18 x 18 mm |
| Distortion typical (%) | < 0.06 |
| Filter thread | No Filter Threads |
| Fov @ 1/1.8″ | 7.13 x 5.33 mm |
| Fov @ 1/2.0″ | 6.40 x 4.80 mm |
| Fov @ 1/2.5″ | 5.70 x 4.28 mm |
| Fov @ 1/2″ | 6.40 x 4.80 mm |
| Fov @ 1/3.0″ | 4.80 x 3.60 mm |
| Fov @ 2/3″ | 8.50 x 7.09 mm |
| Front diameter | 18 mm |
| Image circle | 11 mm |
| Lens type | Telecentric |
| Operating temperature range | 0 to 40°C |
| Resolution (pixel size) | 11.2 μm |
| Storage temperature range | 0 to 50°C |
| Working ƒ/n | f/16.7 |
| Weight | 78 Grams |
