Rendered illustration: the actual product may differ in appearance.
360° inspection lenses
360° inspection lens, 1/2", C-mount (LS-TCL-0061)
Model LS-TCL-0061
Special inspection optics that image the sides or inner walls of a part in one shot. Connection: flying leads.
Specifications
| Model | LS-TCL-0061 |
|---|---|
| Sensor format | 1/2" |
| Mount | C-Mount |
| Connector | Flying Leads |
| Aov | 37 ° |
| Dimensions approximate | 242.3 x 119 x 139.5 mm |
| Filter thread | No Filter Threads |
| Fov maximum | 10 |
| Fov minimum | 2.5 |
| Image circle | 4.8 mm |
| Installation location | Indoor Use Only |
| LED current | 750 mA |
| Lens type | Multi-View |
| Light color | White |
| Operating relative humidity (%) | 20-85 Non Condensing |
| Operating temperature range | 0 to 40°C |
| Power consumption maximum | 18 Watts |
| Storage temperature range | 0 to 50°C |
| Supply voltage | 24 Volts |
| Working distance @ fov maximum | 1.5 mm |
| Working distance @ fov minimum | 5 mm |
| Working ƒ/n | f/8 |
| Weight | 1485 Grams |
