Line scan lenses
50 mm Line Scan Lens (LS-SPH50)
Model LS-SPH50
50 mm Line Scan Lens. 50 mm F1.7 manual-iris lens with M52 filter thread, F, M42 or PK mount option. At a glance: focal length 50 mm; aperture F1.7 Manual Iris; mount F/M42/PK Option; size dia. 63 x 39.9 mm.
Specifications
| Model | LS-SPH50 |
|---|---|
| Focal length | 50 mm |
| Aperture | F1.7 Manual Iris |
| Size | dia. 63 x 39.9 mm |
| Filter thread | M52 x P0.75-7H |
| Mount | F/M42/PK Option |
| Weight | 210 g |
| Shipping weight (estimated) | 0.39 kg |
Applications
- Colour sorter machines
Complete the station
The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.
Configure a system Selection guideOther sizes in the Line Scan lenses series
| Model | Size | Price | Availability | |
|---|---|---|---|---|
| LS-SLS04020-M42 | 20 mm, 0.12x, M42-mount | $1,019.00 | 3 in stock | View |
| LS-SLS2003-M42 | 20 mm, 0.1x, M42-mount | $1,019.00 | 5 in stock | View |
| LS-SLS3501-4K | 35 mm | Price on request | 2 in stock | View |
| LS-SLS3502 | 35 mm, 0.05x | $1,069.00 | 4 in stock | View |
| LS-SMZ-LS5001-65M | 50 mm, 0.5x, 65 MP, M58-mount | $1,119.00 | 5 in stock | View |
| LS-SPH5028 | 50 mm, 0.094x, M42-mount | $1,119.00 | 2 in stock | View |
| LS-SLS2003CV | 20 mm, 0.0358x, V-mount | $1,389.00 | 2 in stock | View |
| LS-SLS2502 | 25 mm, 0.03x, M42-mount | $1,409.00 | 4 in stock | View |
| LS-SLS2801V | 29 mm, 0.1x, V-mount | $1,419.00 | 2 in stock | View |
| LS-SLS3508V | 35 mm, 0.08x, V-mount | $1,439.00 | 5 in stock | View |
| LS-SLS4005M72 | 40 mm, 0.05x, M72-mount | $1,459.00 | 3 in stock | View |
| LS-SLS4010V | 40 mm, 0.1x, V-mount | $1,459.00 | 4 in stock | View |
| LS-SLS04050 | 50 mm, 0.32x, M42-mount | $1,489.00 | 2 in stock | View |
| LS-SLS5025-8K | 50 mm | Price on request | 4 in stock | View |
| LS-SLS6002-8K | 60 mm, 0.2x | Price on request | 3 in stock | View |
| LS-SLS6004-8K | 60 mm, 0.04x | Price on request | 3 in stock | View |
| LS-SLS6016V | 60 mm, 0.167x, V-mount | $1,519.00 | 4 in stock | View |
| LS-SLS8003V | 80 mm, 0.3x, V-mount | $1,589.00 | 4 in stock | View |
| LS-SLS8002V | 100 mm, 0.2x, V-mount | $1,659.00 | 2 in stock | View |
| LS-SLS1202V | 116 mm, 0.2x, V-mount | $1,709.00 | 5 in stock | View |
| LS-SLS1203V | 116 mm, 0.33x, V-mount | $1,709.00 | 2 in stock | View |
| LS-SLS1205V | 116 mm, 0.5x, V-mount | $1,709.00 | 5 in stock | View |
| LS-SLS1207V | 116 mm, 0.75x, V-mount | $1,709.00 | 3 in stock | View |
| LS-SLS1208V | 116 mm, 0.806x, V-mount | $1,709.00 | 5 in stock | View |
