Machine vision lenses
35 mm, 1/1.8", 6 MP, C-mount Machine Vision Lens (LS-SFA3524-6M)
Model LS-SFA3524-6M
35 mm, 1/1.8", 6 MP, C-mount Machine Vision Lens. SP-series 35 mm, 1/1.8" 6 MP C-mount machine vision lens, F2.8-16 manual iris, distortion -0.03%. At a glance: focal length 35 mm; format 1/1.8" (dia. 9.5 mm); resolution 6.0 Megapixel (2.4 μm pixel size); aperture F2.8~16 Manual iris; mount C.
Specifications
| Model | LS-SFA3524-6M |
|---|---|
| Format | 1/1.8" (dia. 9.5 mm) |
| Resolution | 6.0 Megapixel (2.4 μm pixel size) |
| Focal length | 35 mm |
| Aperture | F2.8~16 Manual iris |
| Angle of view (1/1.8") | 15 x 12 x 8 deg |
| M.O.D. | 0.2 m |
| Distortion (TV) | 0.03% |
| Filter thread | M27 x P0.5 |
| Relative illumination | 80% |
| Transmission | AT486~656nm T≥85% |
| Total track length (TTL) | 53.2 mm |
| CRA | 5.5° |
| Size | dia. 33 x 29.4 mm |
| Mount | C |
| Weight | 70 g |
| Notes | 7G Element |
| Shipping weight (estimated) | 0.20 kg |
Complete the station
The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.
Configure a system Selection guideOther sizes in the 1/1.8" machine vision lenses series
| Model | Size | Price | Availability | |
|---|---|---|---|---|
| LS-SFA0420-5M | 4 mm, 1/1.8", 5 MP, C-mount | $99.00 | 5 in stock | View |
| LS-SFA0620-5M | 6 mm, 1/1.8", 5 MP, C-mount | $99.00 | 2 in stock | View |
| LS-SFA0820-5M | 8 mm, 1/1.8", 5 MP, C-mount | $99.00 | 5 in stock | View |
| LS-SFA0822-5M | 8 mm, 1/1.8", 5 MP, C-mount | $99.00 | 4 in stock | View |
| LS-SFA35H24-3M | 3.5 mm, 1/1.8", 3 MP, C-mount | $99.00 | 3 in stock | View |
| LS-SFA1220-5M | 12 mm, 1/1.8", 5 MP, C-mount | $109.00 | 4 in stock | View |
| LS-SFA1222-5M | 12 mm, 1/1.8", 5 MP, C-mount | $109.00 | 4 in stock | View |
| LS-SFA1620-5M | 16 mm, 1/1.8", 5 MP, C-mount | $109.00 | 4 in stock | View |
| LS-SFA2520-5M | 25 mm, 1/1.8", 5 MP, C-mount | $129.00 | 5 in stock | View |
| LS-SFA3520-5M | 35 mm, 1/1.8", 5 MP, C-mount | $139.00 | 5 in stock | View |
| LS-SFA5028-5M | 50 mm, 1/1.8", 5 MP, C-mount | $159.00 | 5 in stock | View |
| LS-SFA7528-5M | 75 mm, 1/1.8", 5 MP, C-mount | $189.00 | 4 in stock | View |
