Portable optical test stand (LS-PTF340200)
Model LS-PTF340200
Small, light portable optical test platform developed for machine vision engineers to carry and demonstrate vision inspection at customer sites. It has two height-adjustable stainless steel columns, one for the light and one for the industrial camera; each has three degrees of freedom (any height adjustment and any movement in the plane), and the clamps fit almost every type of industrial camera and light.
Features
- Clean, simple appearance
- Camera and light can be moved up and down or rotated freely
- Easy to install and operate
- Wide range of use
- Light weight, easy to carry
- Highly adaptable (fits different industrial cameras and lights)
- Aluminium alloy, sturdy and durable
Specifications
| Model | LS-PTF340200 |
|---|---|
| Construction (from illustration) | Base plate with buttons, digital display and indicator light; main shaft with camera mounting bracket (moving slider, front/back and up/down adjustment knobs, slider locking knob, hand-screw) and light mounting bracket |
| Shipping weight | 5.70 kg |
Applications
- Carrying to customer sites to demonstrate vision inspection projects
