Analog controller, high cost-effective (PS), 2 ch, 24 W (LS-PS2424-2)
Model LS-PS2424-2
Small power analog controller: simple structure, compact volume, DIN guide rail installation, external trigger, stepless luminance adjustment and voltage display.
Features
- Simple structure, compact volume, DIN guide rail installation
- External trigger function
- Luminance stepless adjustment
- Voltage display function
- Normal on / normal closed mode optional
- 12V 500mA output to supply other devices (e.g. camera)
- Low level trigger: input 0-1.5V to the +/- port (or short +/-) to trigger
- Trigger delay T1 <= 200us, T3 <= 200us
Specifications
| Model | LS-PS2424-2 |
|---|---|
| Input voltage | AC 100-240V |
| Input frequency | 50/60Hz |
| Output voltage range | 12-24V |
| Luminance control method | knob adjusting |
| Luminance control mode | Constant-voltage |
| Luminance control level | stepless adjustment |
| External trigger voltage | 0-1.5V (low level) |
| Addition output voltage | 12V/500mA (power supply to camera; never reverse-connect) |
| Normal on/normal closed mode switch | built-in (toggle switch TS) |
| Mounting | DIN guide rail mounting base; 4-M3 holes usable after removing the 4 support arms |
| Channels | 2 |
| Output voltage | 12-24V |
| One way max. output power | 24W |
| Total output power | 24W |
| External trigger support | Y |
| Shipping weight | 0.70 kg |
