POE light control module, 1 ch, 24 W (LS-POE2424A-1)
Model LS-POE2424A-1
PoE-powered light control module supporting IEEE 802.3af and IEEE 802.3at, small, light and highly integrated, with 0-255 level PWM output at 24 V up to 1 A, brightness set over Ethernet with PC software, software trigger and parameters saved at power-off.
Features
- PoE powered, supports IEEE 802.3af and IEEE 802.3at
- Small size, light weight, high integration
- 0-255 level PWM output, output voltage 24V, max current 1A
- Ethernet communication: brightness adjusted over the network (PC software)
- Supports software trigger; parameters saved automatically at power-off
Specifications
| Model | LS-POE2424A-1 |
|---|---|
| Operating temp/humidity | 0~40 °C, 20~85 %RH (non-condensing) |
| Storage temp/humidity | 20~60 °C, 20~85 %RH (non-condensing) |
| Drive method | Constant voltage |
| Light control mode | 0-255 level PWM |
| Communication interface | RJ45 (Ethernet) |
| Power interface | RJ45 (PoE power) |
| PoE standard | IEEE 802.3af and IEEE 802.3at |
| Channels | 1 |
| Output voltage | DC 24V |
| Max output current | 1A |
| Total power | 24W |
| Output port | SMP-03V-BC (1: output+ 2: NC 3: output-) |
| Cooling method | Natural cooling |
| Dimensions | 122.5 x 28 x 24 mm |
| Drawing dimensions (mm) | 122.5 L (113.5 body) x 28 W x 24 H |
| Total output (W) | 24 |
| Trigger | Software trigger |
| Shipping weight | 0.20 kg |
