Home / Lighting / Light controllers / 2 channel low-current light controller (NTC-C00055E)
2 channel low-current light controller (NTC-C00055E), 2 ch (LS-NTC-C00055E-2)

Light controllers

2 channel low-current light controller (NTC-C00055E), 2 ch (LS-NTC-C00055E-2)

Model LS-NTC-C00055E-2

$209.00 USDIn stock · 5 available

Inventory updated Oct 15, 2026

0.70 kg shipping weight · Ships in 2-3 weeks

Need volume or project pricing?

Build a system with this light → Matching lens, light, controller and cables, checked for fit

  • Secure checkout by ShopifyCard, PayPal, Venmo, Shop Pay or Google Pay
  • 90-day returnsUnused items; free return label in the US · Returns policy
  • Tracked UPS or DHL shippingExact cost shown at checkout · Shipping policy
  • Questions about fit?Contact us; we reply within one business day
Datasheet (PDF) - LS-NTC-C00055E-2

Features

  • Each channel functions individually with external trigger input
  • 256 levels of intensity adjustment
  • Maximum output current 5mA,output voltage 5V of each channel

Specifications

ModelLS-NTC-C00055E-2
Power supplyDC24V
Max.output current of each channel0~5mA
Max.output voltage of each channel5v
Channels2
Intensity levels0~255
External trigger modeContinuous,Switched,Strobe
External trigger voltage5~24V
Internal output pulse-width1ms-999ms,in steps of 1ms
Communication portRS-232
Baud rate and data format9600/data bit, 8/stop bit, 1/no parity
Operating EnvironmentTemperature 0~40°C / Humidity 25%~85%
Installation modeDIN
Dimensions(mm)60*68*98
Weight0.45Kg
ControlDigital, 256 levels (0~255), RS-232
