Lighting accessories
Cable, 660±5 nm (LS-LW-CP-M-T0027A)
Model LS-LW-CP-M-T0027A
Cable, 660±5 nm. 660 nm wavelength, line-shaped beam Assisted optical path adjustment for faster setup
Features
- 660 nm wavelength, line-shaped beam
- Assisted optical path adjustment for faster setup
Specifications
| Model | LS-LW-CP-M-T0027A |
|---|---|
| Best working distance | 100 ~ 500 mm |
| Laser power | 120 mW |
| Field of view | 75° |
| Spot shape | Line-shaped light spot |
| Dimension | 37.1 mm × Φ27 mm |
| Weight | Approx. 95 g |
| Temperature | Operating temperature: 0 to 60 °C, Storage temp.: -40 to 85 °C |
| Humidity | < 80%RH |
| Ingress protection | IP65 |
| Wavelength | 660±5 nm |
| Beam divergence angle | 75° |
| Maximum power | 120 mW |
| Shipping weight (estimated) | 0.23 kg |
