Line Scan Light, 270 mm, IR 808 nm (LS-LTVM-H-270-IR808)
Model LS-LTVM-H-270-IR808
Line Scan Light, 270 mm, IR 808 nm. VCSEL-packaged LEDs for stronger near-infrared output Structural and fan cooling extends light service life
Features
- VCSEL-packaged LEDs for stronger near-infrared output
- Structural and fan cooling extends light service life
- Multi-side mounting for flexibility
Specifications
| Model | LS-LTVM-H-270-IR808 |
|---|---|
| Color | IR808 |
| Best working distance | 50 ~ 90 mm |
| Line width | < 4 mm @ 70 ± 20 mm |
| Field of view width | 270 mm |
| Power | 263 W max |
| Connector type | 19M-8H (cable not included) |
| Dimension | 316 mm × 142.5 mm × 71 mm |
| Emitting area dimension | 270 mm × 22 mm |
| LED rows | 1 |
| Weight | 3.15 kg |
| Cable length | Additional options |
| Temperature | Operating temp.: 0 to 40 °C, Storage temp.: -20 to 70 °C |
| Humidity | 20% RH to 90% RH (no condensation) |
| Laser safety class | Class 4 |
| Wavelength | 808±8 nm |
| Beam divergence angle | 15±3 ° |
| Maximum power | 96 W |
| Nominal ocular hazard distance (NOHD) | 9.2 m |
| Max. permissible exposure | 4.73 × 10^-7 W/m2 |
| Shipping weight (estimated) | 4.51 kg |
