Bar Light, 900 x 40 mm, White (LS-LLDS-H-900-40-W)
Model LS-LLDS-H-900-40-W
Bar Light, 900 x 40 mm, White. The irradiation direction and angle can be adjusted freely. Support multi-side installation.
Features
- The irradiation direction and angle can be adjusted freely.
- Support multi-side installation.
- Features high-quality LED particles, stable lighting, and high brightness.
Specifications
| Model | LS-LLDS-H-900-40-W |
|---|---|
| Color | White |
| Center illuminance/irradiance | ≥ 29000 lux@100 mm |
| Best working distance | 30 mm to 500 mm |
| Color temperature | W: 6000K to 7500K |
| Power | 93.9 W |
| Connector type | Dual-channel SMR-03V-B |
| Dimension | 828 mm × 40 mm × 30 mm |
| Emitting area dimension | 816 mm × 31.6 mm |
| LED rows | 6 |
| Weight | 1.6 kg |
| Cable length | 1 m |
| Temperature | Working temperature: 0 °C to 40 °C (32 °F to 104 °F); Storage temperature: –20 °C to 60 °C (–4 °F to 140 °F) |
| Humidity | 20% RH to 90% RH (no condensation) |
| Diffuse plate included | PMMA |
| Safety class | No danger |
| Shipping weight (estimated) | 2.34 kg |
Complete the station
Drive the light from a light controller and pair it with a lens for your field of view and working distance.
Light controllers LensesSelection guideOther sizes in the Bar lights series
| Model | Size | Power | Price | Availability | |
|---|---|---|---|---|---|
| LS-LLDS-H-800-30-IR850 | 800 x 30 mm, IR 850 nm | 45.1 W | $419.00 | 5 in stock | View |
| LS-LLDS-H-800-30-IR940 | 800 x 30 mm, IR 940 nm | 45.8 W | $419.00 | 2 in stock | View |
| LS-LLDS-H-800-40-W | 800 x 40 mm, White | 70.9 W | $419.00 | 2 in stock | View |
| LS-LLDS-H-800-40-R | 800 x 40 mm, Red | 47.8 W | $419.00 | 2 in stock | View |
| LS-LLDS-H-800-40-B | 800 x 40 mm, Blue | 61 W | $419.00 | 5 in stock | View |
| LS-LLDS-H-800-40-IR850 | 800 x 40 mm, IR 850 nm | 68.6 W | $419.00 | 3 in stock | View |
| LS-LLDS-H-800-40-IR940 | 800 x 40 mm, IR 940 nm | 68.6 W | $419.00 | 3 in stock | View |
| LS-LLDS-H-900-30-W | 900 x 30 mm, White | 60.2 W | $459.00 | 5 in stock | View |
| LS-LLDS-H-900-30-R | 900 x 30 mm, Red | 35.8 W | $459.00 | 5 in stock | View |
| LS-LLDS-H-900-30-B | 900 x 30 mm, Blue | 45.6 W | $459.00 | 4 in stock | View |
| LS-LLDS-H-900-30-IR850 | 900 x 30 mm, IR 850 nm | 50.6 W | $459.00 | 5 in stock | View |
| LS-LLDS-H-900-30-IR940 | 900 x 30 mm, IR 940 nm | 51.6 W | $459.00 | 2 in stock | View |
| LS-LLDS-H-900-40-R | 900 x 40 mm, Red | 53.8 W | $459.00 | 2 in stock | View |
| LS-LLDS-H-900-40-B | 900 x 40 mm, Blue | 68.6 W | $459.00 | 3 in stock | View |
| LS-LLDS-H-900-40-IR850 | 900 x 40 mm, IR 850 nm | 76.1 W | $459.00 | 3 in stock | View |
| LS-LLDS-H-900-40-IR940 | 900 x 40 mm, IR 940 nm | 77.3 W | $459.00 | 4 in stock | View |
| LS-LLDS-H-1000-30-W | 1000 x 30 mm, White | 67.1 W | $509.00 | 5 in stock | View |
| LS-LLDS-H-1000-30-R | 1000 x 30 mm, Red | 39.8 W | $509.00 | 2 in stock | View |
| LS-LLDS-H-1000-30-B | 1000 x 30 mm, Blue | 50.9 W | $509.00 | 3 in stock | View |
| LS-LLDS-H-1000-30-IR850 | 1000 x 30 mm, IR 850 nm | 56.4 W | $509.00 | 3 in stock | View |
| LS-LLDS-H-1000-30-IR940 | 1000 x 30 mm, IR 940 nm | 57.4 W | $509.00 | 5 in stock | View |
| LS-LLDS-H-1000-40-W | 1000 x 40 mm, White | 104.5 W | $509.00 | 4 in stock | View |
| LS-LLDS-H-1000-40-R | 1000 x 40 mm, Red | 59.5 W | $509.00 | 4 in stock | View |
| LS-LLDS-H-1000-40-B | 1000 x 40 mm, Blue | 76.3 W | $509.00 | 5 in stock | View |
