Line scan lights
184 x 20 mm Waterproof line light (IP series) (LS-LIN18420)
Model LS-LIN18420
Light for humid, dusty or harsh environments with a special leakproof structure and heat-dissipating material; passed 12 h dust-box and 12 h sprinkler tests and holds IP54 certification from SGS.
Features
- For humid, dusty or relatively harsh environments
- Special structure design with high leakproofness
- Special heat dissipating material
- Variety of outlines, can be customized
- IP54 waterproof certification from SGS
Specifications
| Model | LS-LIN18420 |
|---|---|
| Voltage | 24 V |
| Adapted controller | Analog controller, digital controller |
| Protection | IP54 (SGS certified) / IP67 level |
| Dustproof test | 12 h in a professional dust box with continuous dust drift |
| Waterproof test | 12 h spray by professional sprinkler at 800 mm |
| Customizable | shape, colour and colour temperature, cable length, installation method, multi-area control |
| Operating temperature | 0-50 °C |
| Operating humidity | 20-85% (non-condensing) |
| Life span | 50000 h (to 50% of factory-default luminance) |
| Extension cable options | PVC extension cable (high flexibility, bending and heat resistant, for use inside equipment) or high-flexibility extension cable (harder and more abrasion resistant than PVC, for drag-chain production lines) |
| Custom wavelengths | UV & IR light can be customized as required |
| Power (W) | 44.4 |
| Weight (g) | 965 |
| Emitting surface (mm) | 184 x 20 |
| Mounting | 2 x 4-M3 depth 4 |
| Dimension drawing | 9 |
| Common | N |
Applications
- Humid, dusty or relatively harsh environments
