Dome lights
Dome Light, 100 mm dia., White (LS-LGSH-100-W)
Model LS-LGSH-100-W
Dome Light, 100 mm dia., White. Low-angle shadow-free illumination Reduces reflections and LED glare
Features
- Low-angle shadow-free illumination
- Reduces reflections and LED glare
Specifications
| Model | LS-LGSH-100-W |
|---|---|
| Color | White |
| Color temperature | 6000 ~ 7000K |
| Irradiation angle | 26.7° |
| Connector type | SMR-03V-B |
| Power | 5.9 W |
| Cable length | 500 mm |
| Dimension | Φ100 × 40 mm |
| Outer dimension | Φ100 mm |
| Bore dimension | Φ71 mm |
| Emitting area outer diameter | Φ92 mm |
| Temperature | Working temperature: 0 °C to 40 °C (32 °F to 104 °F); Storage temperature: –20 °C to 60 °C (–4 °F to 140 °F) |
| Humidity | 20% to 85% RH (non-condensing) |
| Diffuse plate included | Included |
| Shipping weight (estimated) | 0.66 kg |
Complete the station
The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.
Configure a system Selection guideOther sizes in the Dome lights series
| Model | Size | Power | Price | Availability | |
|---|---|---|---|---|---|
| LS-LGSH-50-W | 50 mm dia., White | 2.6 W | $109.00 | 2 in stock | View |
| LS-LGSH-180-W | 180 mm dia., White | 15 W | $459.00 | 2 in stock | View |
