Light controllers
APL constant current power supply, 4 ch (LS-HAPL515-4T)
Model LS-HAPL515-4T
The LS-HAPL515-2T constant-current controller provides stable, controllable power for 5 V spot lights; brightness is adjusted steplessly by voltage control and each channel can output up to 680 mA. A stable, convenient, fast, high-response controller for industrial lighting.
Features
- Stepless knob for precise brightness adjustment
- Two channels controlled independently for precise control
- 0-680 mA constant current for spot lights
Specifications
| Model | LS-HAPL515-4T |
|---|---|
| Input voltage | AC100-240V 50/60Hz |
| Output voltage | 5V |
| Control | Stepless knob |
| Trigger input | No |
| Front panel | Stepless knobs, power switch |
| Rear panel | Power input, light outputs, ground terminal |
| Channel / output | C4 O2 (printed "4 channels, 2 outputs") |
| Single channel current | 0-680mA |
| Total output current | 2.72A |
| Control (perform) | Knob |
| Channels | 4 |
| Shipping weight | 0.50 kg |
Complete the station
Drive the light from a light controller and pair it with a lens for your field of view and working distance.
Light controllers LensesSelection guideOther sizes in the APL constant current power supply series
| Model | Size | Price | Availability | |
|---|---|---|---|---|
| LS-HAPL515-2T | 2 ch | $129.00 | 2 in stock | View |
