APC analog power supply controller, 1 ch (LS-HAPC2424P-1T)
Model LS-HAPC2424P-1T
APC series analog controllers provide brightness-control power for 24 V LED lights. Brightness is set precisely with stepless knobs on the front panel; the units have four light outputs, can stay lit for long periods and have a built-in external trigger for easy on/off switching.
Features
- Stepless knob for precise brightness adjustment
- Light on/off switch for easy trigger-on or trigger-off
- High-speed optocoupler-isolated trigger
- Channels controlled independently for precise control
Specifications
| Model | LS-HAPC2424P-1T |
|---|---|
| Input voltage | AC100-240V 50/60Hz |
| Output voltage | 0-24 V |
| Control | Stepless knob |
| Front panel | Power switch, brightness knob(s), constant-on / constant-off switch |
| Rear panel | External trigger port, AC socket, FG terminal, light output ports |
| Panel note | Front panels for different channel counts differ only in the output channels and trigger port; outer dimensions are identical. One channel drives one light output. |
| Channel / output | C1 O1 (1 channel, 1 output) |
| Single channel current | 1A |
| Total output current | 1A |
| Control (perform) | Knob |
| Trigger input | Yes |
| Channels | 1 |
| Shipping weight | 0.50 kg |
