8 mm, 2/3", 8 MP, C-mount machine vision lens (LS-FFL-0355)
  • 8 mm, 2/3", 8 MP, C-mount machine vision lens (LS-FFL-0355)

Machine vision lenses

8 mm, 2/3", 8 MP, C-mount machine vision lens (LS-FFL-0355)

Model LS-FFL-0355

  • Focal length8 mm
  • MountC-mount
  • Sensor2/3"
  • Sensor format2/3"
$139.00

Ships in 2-3 weeks

0.3 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

8 mm, 2/3", 8 MP, C-mount machine vision lens (LS-FFL-0355)LS-FFL-0355

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

LS-FFL-0355: focal length 8 mm, iris (F/#) 2.8-11, mount C.

8 mm, 2/3", 8MP, C-mount Machine Vision Lens. 2/3 Inch 8 MP Industrial Lens.

  • Tracked worldwide shippingTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-FFL-0355

Optics

Focal length (mm)8
Iris (F/#)2.8-11
Format size (")2/3

Mechanical

MountC
Shipping weight (estimated)0.30 kg

Engineering data

Field of view with the LS-FFL-0355

Worked out from this lens's own focal length, image circle and closest focus: what it sees at your working distance, on the sensor you use.

Focal length8 mm
Image circleØ 11 mmCovers sensors up to 2/3"
Angle of view55.7° × 47.7°Calculated for a 2/3" sensor; 69.1° diagonal
Field of view (width × height) of the 8 mm lens by sensor format and working distance
Sensor formatAt 32 mmAt 100 mmAt 200 mmAt 500 mm
1/2.9"4.98 × 3.74 mm19.9 × 15 mm62.3 × 46.8 mm125 × 93.5 mm311 × 234 mm
1/2"6.4 × 4.8 mm25.6 × 19.2 mm80 × 60 mm160 × 120 mm400 × 300 mm
1/1.8"7.07 × 5.3 mm28.3 × 21.2 mm88.4 × 66.2 mm177 × 132 mm442 × 331 mm
2/3"8.45 × 7.07 mm33.8 × 28.3 mm106 × 88.4 mm211 × 177 mm528 × 442 mm

Thin-lens approximation: field of view ≈ sensor size × working distance ÷ focal length, with the distance measured to the front of the lens; closest to reality when the distance is many times the focal length. Sensor sizes are typical for each optical format.

Compatible parts

Fits with this part

Checked with the configurator's fit rules: lens mount and sensor coverage, supply voltage, power per channel and connector.

Build the full system with this part

Cameras this lens fits

7.1 mm sensor diagonal; this lens covers up to 11 mm

9.5 mm sensor diagonal; this lens covers up to 11 mm

3.2 mm sensor diagonal; this lens covers up to 11 mm

6.6 mm sensor diagonal; this lens covers up to 11 mm

8.9 mm sensor diagonal; this lens covers up to 11 mm

8.8 mm sensor diagonal; this lens covers up to 11 mm

Adapters

For CS-mount cameras

Other models in the 2/3 inch 8MP industrial lens (LS-FFL-S66) series

See all 6 models
ModelSizeFocal lengthPriceAvailabilityLink
LS-FFL-0355This model8 mm, 2/3", 8MP, C-mount8 mm$139.00 Ships in 2-3 weeks
LS-FFL-035612e mm, 2/3", 8MP, C-mount12e$139.00 Ships in 2-3 weeks View
LS-FFL-036050 mm, 2/3", 8MP, C-mount50 mm$199.00 Ships in 2-3 weeks View
LS-FFL-035716 mm, 2/3", 8MP, C-mount16 mm$209.00 Ships in 2-3 weeks View
LS-FFL-035825 mm, 2/3", 8MP, C-mount25 mm$229.00 Ships in 2-3 weeks View
LS-FFL-035935 mm, 2/3", 8MP, C-mount35 mm$259.00 Ships in 2-3 weeks View
