Rendered illustration: the actual product may differ in appearance.
Machine vision lenses
16 mm lens, 1", C-mount (LS-FFL-0050)
Model LS-FFL-0050
Machine vision lens for industrial cameras. Minimum object distance 100 mm.
Specifications
| Model | LS-FFL-0050 |
|---|---|
| Focal length | 16 mm |
| Sensor format | 1" |
| Mount | C-Mount |
| Minimum object distance | 100 mm |
| Aov @ 1/1.8″ h°×v°×d° | 25.5 × 19.2 × 31.6° |
| Aov @ 1″ h°×v°×d° | 43.6 × 33.6 × 53.2° |
| Aov @ 2/3″ h°×v°×d° | 30.9 × 23.4 × 38.1° |
| Aperture (max) | f/2.4 |
| Back focal length | 10.7 mm |
| Dimensions | 39.5 × 39.5 × 47 mm |
| Filter thread | M37.5-0.5 |
| Focus control | Manual |
| Focus range | 0.1 m - ∞ |
| Front diameter | 20.9 mm |
| Image circle | 16 mm |
| Image size dimensions | 12.8 mm x 9.6 mm |
| Iris control | Manual |
| Lens type | Fixed Focal Length |
| Operating temperature range | -10 to +50 °C |
| Rear effective diameter | 15.9 mm |
| Resolution (MP) | 20 |
| Spectrum | Visible |
| Zoom range | Fixed |
| Weight | 108.1 |
