Home / Lenses / Machine vision lenses / 1.05 mm lens, 1/2.5", M12-0.5-mount

1.05 mm lens, 1/2.5", M12-0.5-mount (LS-FFL-0015)

Rendered illustration: the actual product may differ in appearance.

Machine vision lenses

1.05 mm lens, 1/2.5", M12-0.5-mount (LS-FFL-0015)

Model LS-FFL-0015

Machine vision lens for industrial cameras.

Datasheet (PDF) - LS-FFL-0015 3D model (STEP) - LS-FFL-0015

Specifications

Model	LS-FFL-0015
Focal length	1.05 mm
Sensor format	1/2.5"
Mount	M12-0.5
IP rating	IP66
Aov @ 1/1.7″ h°×v°×d°	180.0°
Aov @ 1/3″ h°×v°×d°	180.0 × 163.2°
Aov @ 1/4″ h°×v°×d°	163.2 × 130.2 × 180.0°
Back focal length	3.62 mm
Dimensions	27 × 27 × 29.88 mm
Filter thread	No Filter Threads
Focus range	0.05 m - ∞
Front diameter	20 mm
Image circle	4.1 mm
Lens type	Fisheye
Rear effective diameter	5.4 mm
Resolution (MP)	5
Spectrum	Visible
Working ƒ/n	f/2.8
Zoom range	Fixed
Weight	17.3

Complete the station

The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.
