Home / Lenses / Machine vision lenses / 1.65 mm lens, 1/1.7", M12-0.5

1.65 mm lens, 1/1.7", M12-0.5 (LS-FFL-0014)

Rendered illustration: the actual product may differ in appearance.

Machine vision lenses

1.65 mm lens, 1/1.7", M12-0.5 (LS-FFL-0014)

Model LS-FFL-0014

1.65 mm lens, 1/1.7", M12-0.5.

3D model (STEP) - LS-FFL-0014

Specifications

Model	LS-FFL-0014
Filter Thread	No Filter Threads
Focal Length	1.65 mm
Focus Range	Fixed
Front Diameter	18.4 mm
Image Circle Diameter	5.38 mm
Imager Format	1/1.7"
Lens Type	Fisheye
Light Spectrum	Visible + NIR
Mount	M12-0.5
Resolution (MP)	12
Working ƒ/N	f/2.8

Complete the station

The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.
