Rendered illustration: the actual product may differ in appearance.
Machine vision lenses
1.2 mm lens, 1/1.7", M12-0.5-mount (LS-FFL-0013)
Model LS-FFL-0013
Machine vision lens for industrial cameras.
Specifications
| Model | LS-FFL-0013 |
|---|---|
| Focal length | 1.2 mm |
| Sensor format | 1/1.7" |
| Mount | M12-0.5 |
| Aov @ 1/1.7″ h°×v°×d° | 185.0° |
| Aov @ 1/3″ h°×v°×d° | 171.5 × 139.5° |
| Aov @ 1/4″ h°×v°×d° | 139.5 × 110.3 × 164.2° |
| Back focal length | 4.2 mm |
| Dimensions | 29.2 × 29.2 × 25.7 mm |
| Filter thread | No Filter Threads |
| Focus range | Fixed |
| Front diameter | 24.4 mm |
| Image circle | 5.38 mm |
| Lens type | Fisheye |
| Operating temperature range | -20 to +60 °C |
| Rear effective diameter | 5.6 mm |
| Resolution (MP) | 12 |
| Spectrum | Visible + NIR |
| Working ƒ/n | f/2.2 |
| Zoom range | Fixed |
| Weight | 16.3 |
