Representative photo of this series
Light controllers
Hybrid strobe controller, 2/4 channels, 2 ch, 65 W (LS-DV65-F03C-48200-2)
Model LS-DV65-F03C-48200-2
Support RS232 communication. Built-in 48V switching power supply. Low trigger response time (≤10us).
Features
- Support RS232 communication
- Built-in 48V switching power supply
- Low trigger response time (≤10us)
- Support external/internal trigger mode
- Support synchronized signal output
- Power down data is automatically saved
- Provide 12V output interface for camera power supply
- Easy to install, screw mount or C45 mounting rail
- 5~24V trigger, adaptable to high and low level trigger modes
- Support synchronous trigger output, synchronous trigger output signal can be connected to external devices to synchronize the trigger external devices synchronous work
Specifications
| Model | LS-DV65-F03C-48200-2 |
|---|---|
| Maximum output current per channel | Instantaneous 20A |
| Maximum input voltage | AC220V |
| Maximum output voltage | 48V |
| Overheat protection | 65W none, all others have |
| Operating modes | Internal trigger/external trigger |
| Short circuit protection | NO |
| Internal trigger cycle value | 10~999ms |
| Strobe pulse width time | 10~999us |
| Strobe delay time | 0~99us |
| Baud rate | 9600-115200bps optional |
| Trigger mode | Edge (valid in external trigger mode) |
| Operating temperature | 5~50°C |
| Light emitting mode | Strobe |
| Driving mode | Constant voltage |
| Dimension | 114x111x98mm |
| Built-in power supply power | 65W |
| Number of channels | 2 |
| Connected light source type | 10mA~2.5A 24V power supply |
| Catalog page | P65 |
| Total output (W) | 65 |
| Control | digital (buttons, 4-digit display) / RS232 |
| Shipping weight | 0.65 kg |
Complete the station
The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.
Configure a system Selection guideOther sizes in the Hybrid strobe controller, 2/4 channels (DV-F03C) series
| Model | Size | Power | Price | Availability | Link |
|---|---|---|---|---|---|
| LS-DV120-F03C-48200-2 | 2 ch, 120 W | 120 W | $139.00 | 2 in stock | View |
| LS-DV65-F03C-48200-4 | 4 ch, 65 W | 65 W | $159.00 | 3 in stock | View |
| LS-DV120-F03C-24200-4 | 4 ch, 120 W | 120 W | $169.00 | 3 in stock | View |
| LS-DV120-F03C-48200-4 | 4 ch, 120 W | 120 W | $169.00 | 3 in stock | View |
| LS-DV200-F03C-48200-4 | 4 ch, 200 W | 200 W | $199.00 | 2 in stock | View |
