Representative photo of this series
Light controllers
External power digital controller, 8/16 channels, 8 ch (LS-DV-N02C-24030-8)
Model LS-DV-N02C-24030-8
Support RS232 communication. External power supply up to 24V. Low trigger response time.
Features
- Support RS232 communication
- External power supply up to 24V
- Low trigger response time
- Support external trigger mode
- Support millisecond strobe and microsecond strobe
- Brightness and mode can be set manually
- 5~24V trigger, adaptable to high and low level trigger modes
- Small size, easy to install, screw mounting or C45 rail mounting
Specifications
| Model | LS-DV-N02C-24030-8 |
|---|---|
| Maximum input voltage | 24V |
| Maximum output voltage | 24V |
| Overheat protection | NO |
| Working mode | 0: Normally extinguished; 1: Bright; 2: Millisecond strobe; 3: Microsecond strobe |
| Short circuit protection | have |
| Brightness level | 255 levels |
| Millisecond strobe time | 1~999ms |
| Microsecond strobe time | 1~999us |
| Communication baud rate | 9600-115200bps optional |
| Trigger mode | Edge + level trigger |
| Operating temperature | 5~50°C |
| Luminous mode | Normal light, normal extinction, strobe |
| Driving mode | PWM |
| Built-in power supply power | NO |
| Number of channels | 8 |
| Connected light source type | 10mA~3A 24V power supply |
| Maximum output current of single channel | 3A |
| Dimension | 122×97×100mm |
| Catalog page | P28 |
| Control | digital (buttons, 4-digit display) / RS232 |
| Shipping weight | 0.60 kg |
Complete the station
The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.
Configure a system Selection guideOther sizes in the External power digital controller, 8/16 channels (DV-N02C) series
| Model | Size | Price | Availability | Link |
|---|---|---|---|---|
| LS-DV-N02C-24020-16 | 16 ch | $1,109.00 | 3 in stock | View |
