Light controllers
Standard digital controller, box type (DPS ... BHC), 4 ch, 60 W (LS-DPS2460BHC-4T)
Model LS-DPS2460BHC-4T
Digital controller combining constant-on and ON/OFF lighting, with digital display, RS232 communication, screw mounting and a high-speed optocoupler trigger input.
Features
- Constant-on and ON/OFF lighting in one unit
- Digital display, settings easy to confirm
- Communication: RS232
- Mounting: screw
- External trigger input with high-speed optocoupler design, fast and reliable
Specifications
| Model | LS-DPS2460BHC-4T |
|---|---|
| Operating temp/humidity | 0~40 °C, 20~85 %RH (non-condensing) |
| Storage temp/humidity | 20~60 °C, 20~85 %RH (non-condensing) |
| Drive method | Constant voltage |
| Input voltage | AC100-240V 50/60Hz |
| Output voltage | DC 24V |
| Output port | SMP-03V-BC (1: output+ 2: NC 3: output-) |
| Cooling method | Forced cooling |
| Light control mode | 0-255 level PWM control; panel buttons / RS232 |
| PWM frequency | 86KHz |
| Max output current | 2.5A (single channel max current 2.5A) |
| Total power | 60W |
| External trigger voltage | DC5V~24V (current about 5.6mA) |
| Trigger delay | <40μs |
| Weight | <970g |
| Dimensions | 115 x 135 x 67 mm |
| Buttons | CH = channel / function switch (H1 = constant-on mode, H0 = constant-off mode); + increase; - decrease |
| Indicators | Power lit at normal power-on |
| FG terminal | Controller chassis ground |
| Trigger port | U+ (5V isolated power output +), 4+ 3+ 2+ 1+ (CH4-CH1 trigger positive), 4- 3- 2- 1- (negative), U- (5V isolated power output -); DC5-24V, optocoupler isolated; wiring with internal or external power, NPN or PNP |
| Mounting | Screw mounting: 4-M3 through threads; remove the feet to use them as M3 mounting holes; 4-dia.3.5 holes |
| Drawing dimensions (mm) | 135 W (128 / 103) x 115 D (95 / 80) x 67 H (1.5 flange) |
| Channels | 4 |
| Total output (W) | 60 |
