Digital controller, DPS series, 8 ch, 120 W (LS-DPS24120C-8TD)
Model LS-DPS24120C-8TD
Digital controller with brightness set by panel keys, serial or network communication, switchable digital or strobe mode, optocoupler-isolated external trigger, power-failure memory and overload/short-circuit protection.
Features
- Key / serial communication / network communication brightness control
- Digital mode or strobe mode can be switched
- External trigger with high-speed optocoupler isolation reduces trigger delay
- Power failure saving function
- Overload and short-circuit protection
Specifications
| Model | LS-DPS24120C-8TD |
|---|---|
| Operating temp/humidity | 0~40 °C, 20~85 %RH (non-condensing) |
| Storage temp/humidity | 20~60 °C, 20~85 %RH (non-condensing) |
| Drive method | Constant voltage |
| Light mode | 256 level PWM control; panel key / RS232 / Ethernet |
| PWM frequency | 250KHz |
| Input voltage | AC100-240V 50/60Hz |
| Channel | 8 |
| Output voltage | 24V |
| Max output current | 5A (single channel max current 3A) |
| Total power | 120W |
| Output port | SMP-03V-BC (1: input+, 2: NC, 3: output-) |
| External trigger voltage | DC5V~24V (current about 5.6mA) |
| Trigger delay | Strobe mode <5us, digital mode <8us |
| Cooling method | Forced cooling |
| Weight | 720g |
| Dimensions (mm) | 116 W x 164.8 H x 111.4 D (100 body depth) |
| Mounting | 35 mm DIN rail (C45) |
| Trigger port | COM, 1-8, COM (COM interlinked, no polarity); NPN or PNP control |
| Channels | 8 |
| Total output (W) | 120 |
| Control | Panel keys / RS232 / Ethernet |
