Digital control box (DPC), 4 ch, 60 W (LS-DPC2460-4F)
Model LS-DPC2460-4F
Digital control box with DC 24V input: each channel controlled independently with high precision, RS232 communication with PC, trigger input, power-off saving and a 12V 500mA output.
Features
- Input voltage: DC24V
- Each channel controlled independently with high precision
- Communicates with PC by RS232
- Trigger, fast response, high reliability
- Power off saving function
- 12V 500mA output to supply other devices
Specifications
| Model | LS-DPC2460-4F |
|---|---|
| Input voltage | DC 24V |
| Output voltage range | 0-24V |
| Addition output voltage | 12V 500mA |
| Baud rate | 9600bps |
| Luminance control method | manual adjust by button, PC remote adjustment |
| Luminance control mode | PWM duty ratio |
| Luminance control level | 256 level |
| Saving function | luminance kept when power off |
| External trigger voltage | 5-24V high level trigger |
| Communication | RS232 |
| Normal on/normal closed mode switch | change H mode by CH button (H1 normal on, H0 normal closed) |
| Mounting | DIN guide rail mounting base |
| Channels | 4 |
| Output voltage | 0-24V |
| One way max. output power | 30W |
| Total output power | 60W |
| External trigger support | Y |
| Shipping weight | 0.35 kg |
