DC65 digital controller, 4 ch, 65 W (LS-DC65-P01CE-05008-2)
Model LS-DC65-P01CE-05008-2
4-channel digital light controller with built-in 65W 5V switching power supply for 5V point light sources, RS232 and 100-megabit Ethernet communication, constant-on / strobe modes with millisecond and microsecond strobe.
Features
- Support for RS232 communication
- Support for 100-megabit Ethernet communication
- Built-in 5V switch power supply
- Low trigger response time
- Support the external trigger mode
- Constant bright / strobe can be switched
- Support millisecond and microsecond strobe
- Brightness and mode can be set manually
- 5~24V two-way trigger, adapts to high and low level trigger mode
- Convenient installation: screw installation or C45 rail installation
Specifications
| Model | LS-DC65-P01CE-05008-2 |
|---|---|
| Built-in power supply | 65W |
| Single-channel maximum current | 0.5A |
| Input voltage | AC220V (built-in switch power supply) |
| Output voltage | 5V |
| Output | 0.5A (single channel maximum current 0.8A, factory limit according to demand) |
| Overcurrent protection | none |
| Overvoltage protection | none |
| Work modes | Five: NORMAL 0 = normal bright, 1 = normally off, 2 = constant bright; STROBE 0 = 1~999 ms strobe, 1 = 10~999 us strobe |
| Luminescence mode | Normal bright / constant off / constant bright / strobe (all except constant bright can be trigger controlled) |
| Trigger way | Edge + level trigger (edge in strobe mode, level in normal modes) |
| Brightness levels | 255 |
| Millisecond strobe time | 1~999 ms |
| Microsecond strobe time | 10~999 us |
| Communication mode | Serial port (9600 baud, no parity, 8 data bits, 1 stop bit) / 100M Ethernet (default IP 192.168.1.200, TCP server, port 8800) |
| Number of channels | 4 |
| Light source type | 5V point light source (10mA~0.8A) |
| Operating ambient temperature | 5~50℃ |
| Size | See appendix (not included in the document) |
| Trigger response | ≤15us / ≤200us (two values in the timing tables) |
| Panel | 4-digit display, MENU/+/- keys, LOCK/UNLOCK switch, NORMAL/STROBE switch, run and error indicators, T1-T4 trigger terminals, RS232 DB9 female, Ethernet, AC220V inlet |
| Light connector | pin 1 light +, pin 2 light |
| Total output (W) | 65 |
| Control | keys / RS232 / Ethernet |
| Shipping weight | 0.50 kg |
