Representative photo of this series
Light controllers
Digital point light controller, 12 ch, 65 W (LS-DC65-P01C-05008-12)
Model LS-DC65-P01C-05008-12
Controller section 'Digital point light controller' of the light controller selection manual (cards P42-P48).
Features
- Support RS232 communication
- Built-in 5V switching power supply
- Low trigger response time
- Support external trigger mode
- Normal light / strobe can be switched
- Support millisecond strobe and microsecond strobe
- Brightness and mode can be set manually
- 5~24V trigger, adaptable to high and low level trigger modes
- Easy to install, screw mounting or C45 rail mounting
Specifications
| Model | LS-DC65-P01C-05008-12 |
|---|---|
| Maximum input voltage | AC220V |
| Maximum output voltage | 5V |
| Overheat protection | NO |
| Working mode | NORMAL: 0: Normally extinguished, 1: Bright, 2: Millisecond strobe; STROBE: 0: 1~999ms strobe, 1: 10~999 microseconds strobe |
| Short circuit protection | NO |
| Brightness level | 255 levels |
| Connection light source type | 5V point light source |
| Millisecond strobe time | 1~999ms |
| Communication baud rate | 9600-115200bps optional |
| Trigger mode | Edge + level trigger |
| Operating temperature | 5~50°C |
| Luminous mode | Normal light, normal extinction, constant Brightness, strobe |
| Driving mode | Constant Current |
| Built-in power supply power | 65W |
| Number of channels | 12 |
| Connected light source type | 5V point light source |
| Single channel instantaneous maximum current | 0.8A |
| Dimension | 127×132×162mm |
| Catalog page | P43 |
| Output voltage | 5V |
| Built-in power supply | 65W |
| Max current per channel | 0.8A |
| Communication | RS232 |
| Trigger | 5~24V trigger |
| Mounting | Screw or C45 rail installation |
| Manual page code | P43 |
| Total output (W) | 65 |
| Control | digital (buttons, 4-digit display) / RS232 |
| Shipping weight | 1.20 kg |
Complete the station
The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.
Configure a system Selection guideOther sizes in the Digital point light controller series
| Model | Size | Power | Price | Availability | Link |
|---|---|---|---|---|---|
| LS-DC65-P01C-05008-2 | 2 ch, 65 W | $219.00 | 3 in stock | View | |
| LS-DC65-P01C-05005-4 | 4 ch, 65 W | 65 W | $279.00 | 3 in stock | View |
