Representative photo of this series
Light controllers
Constant current controller, high-speed strobe, 2 ch, 600 W (LS-DC600-L02CE-24125-2)
Model LS-DC600-L02CE-24125-2
High-current digital constant current controllers (high-speed strobe series) with remote control through serial port and network port, temperature-controlled cooling and aviation-plug outputs.
Features
- Digital constant current controller
- Output current up to 9A per channel
- Constant current output, flicker-free brightness
- Parameters saved in real time, no need to set them at every power-on
- Remote parameter control via serial port and network port
- Temperature-controlled heat dissipation
- Trigger level can be set to adapt to different trigger modes
- Trigger debounce filter, stronger anti-interference
- Built-in output short circuit protection
- Remote parameter setting through serial port and network port
- Temperature-controlled cooling
Specifications
| Model | LS-DC600-L02CE-24125-2 |
|---|---|
| Brightness levels | 255 |
| Communication | RS232 communication, 100M Ethernet (printed 'Hundred Gigabit Ethernet') |
| Control | Digital (4-digit display, buttons), RS232, 100M Ethernet |
| Driving mode | Constant current |
| Luminous mode | Constant brightness, constant out, constant brightness strobe |
| Max input voltage | AC220V |
| Operating temperature | 5~50°C |
| Overheat protection | Yes |
| Strobe time | 1~999ms |
| Trigger | External trigger, edge + level |
| Trigger mode | Edge + level trigger |
| Working mode | 0: normally extinguished, 1: normally light, 2: constant light |
| Built-in power supply power | 600W |
| Number of channels | 2 |
| Connected light source type | 24V light source |
| Max output current per channel | 9/12.5A |
| Max output voltage | 48V |
| Short circuit protection | Yes |
| Light source interface | 6-core aviation plug |
| Dimensions (mm) | 291 x 143 x 165 |
| Total output (W) | 600 |
| Shipping weight | 2.45 kg |
Complete the station
The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.
Configure a system Selection guideOther sizes in the Constant current controller, high-speed strobe (L02) series
| Model | Size | Price | Availability | Link |
|---|---|---|---|---|
| LS-DC450-L02CE-48090-2 | 2 ch, 450 W | $379.00 | 3 in stock | View |
| LS-DC600-L02CE-48125-2 | 2 ch, 600 W | $449.00 | 5 in stock | View |
| LS-DC450-L02CE-36020-6 | 6 ch, 450 W | $499.00 | 2 in stock | View |
| LS-DC500-L02CE-36020-6 | 6 ch, 500 W | $519.00 | 4 in stock | View |
