Representative photo of this series
Light controllers
Constant current controller, external 24 V supply, 4 ch (LS-DC-I30C-24020-4)
Model LS-DC-I30C-24020-4
Small digital constant current controller powered from an external 24V supply, with RS232, external triggering and millisecond and microsecond strobe.
Features
- Supports RS232 communication
- Digital constant current controller
- External 24V power supply
- Constant current output, flicker-free brightness
- Low trigger response time
- Supports external trigger mode
- Trigger level can be set to adapt to different trigger modes
- Trigger debounce filter, stronger anti-interference
- Supports millisecond and microsecond strobe
- Brightness and mode can be set manually
- 5~24V trigger, adaptable to high and low level trigger modes
- Small size, easy to install: screw mounting or C45 rail
Specifications
| Model | LS-DC-I30C-24020-4 |
|---|---|
| Baud rate | 9600-115200bps optional |
| Brightness levels | 255 |
| Built-in power supply | No (external 24V supply) |
| Built-in power supply power | NO |
| Connected light source type | 10mA~2A 24V power supply |
| Control | Digital (4-digit display, buttons), RS232 |
| Driving mode | Constant current |
| Luminous mode | Normal light, frequently extinguished, strobe |
| Max input voltage | 24V |
| Max output voltage | 24V |
| Microsecond strobe time | 1~999us |
| Millisecond strobe time | 1~999ms |
| Operating temperature | 5~50°C |
| Overheat protection | No |
| Short circuit protection | No |
| Single channel instantaneous max current | 2A |
| Trigger | 5~24V external trigger, adaptable to high and low level trigger modes; edge + level |
| Trigger mode | Edge + level trigger |
| Working mode | 0: normally extinguished, 1: always on, 2: millisecond strobe, 3: microsecond strobe |
| Number of channels | 4 |
| Dimensions (mm) | 66 x 85.5 x 99 |
| Shipping weight | 0.40 kg |
