Light controllers
High-power constant-current controller (CPL series), 1 ch, 320 W (LS-CPL48320C-1T)
Model LS-CPL48320C-1T
High-power constant-current controller combining constant-on and ON/OFF lighting, with digital display, RS232 and Ethernet communication, screw mounting and a high-speed optocoupler trigger input.
Features
- Constant-on and ON/OFF lighting in one unit
- Digital display, settings easy to confirm
- Communication: RS232 and Ethernet
- Mounting: screw
- External trigger input with high-speed optocoupler design, fast and reliable
Specifications
| Model | LS-CPL48320C-1T |
|---|---|
| Operating temp/humidity | 0~40 °C, 20~85 %RH (non-condensing) |
| Storage temp/humidity | 20~60 °C, 20~85 %RH (non-condensing) |
| Drive method | Constant current |
| Light control mode | Variable current control; panel buttons / RS232 / Ethernet |
| Output voltage | DC 48V |
| External trigger voltage | DC5V~24V (current about 5.6mA) |
| Trigger delay | <100us |
| Cooling method | Forced cooling |
| FG terminal | Controller chassis ground |
| Indicators | Power lit at normal power-on; channel indicator lit when a light is connected |
| Buttons | CH = function switch (H1 = constant-on mode, H0 = constant-off mode); + increase; - decrease |
| Mounting | Screw: 4-M3 fixing holes under the feet (remove the feet to install) |
| Input voltage | AC200-240V 50/60Hz |
| Channels | 1 |
| Max output current | 6.8A |
| Total power | 320W |
| Output port | dia.16 6-pin aviation connector |
| Weight | 3850g or less |
| Dimensions | 113.5 x 285 x 129 mm |
| Trigger port | 1+ / 1- (CH1 external trigger positive / negative); DC5-24V, optocoupler isolated, NPN or PNP |
| Drawing dimensions (mm) | 285 L (267 body; 6.3 front) x 113.5 W (94 holes) x 129 H (123 panel); 4-M3 mounting under feet |
| Total output (W) | 320 |
