Constant current controller (CPL series, 150 W), 2 ch, 150 W (LS-CPL48150B-2T)
Model LS-CPL48150B-2T
Two-channel constant current controller with 1000-step brightness adjustment and an opto-isolated high-speed external trigger. The constant current output keeps brightness stable and prolongs light life; suitable for the LS-HCOS series of coaxial lights.
Features
- 1000-step brightness adjustment (0-999)
- Constant on / constant off mode switch to choose the working mode for the application
- External trigger uses high-speed optocoupler isolation for an accurate, highly reliable trigger signal
- Constant current output ensures stable brightness and prolongs light life
- Suitable for the LS-HCOS series of coaxial lights
- Panel keys and RS232 control
Specifications
| Model | LS-CPL48150B-2T |
|---|---|
| Drive method | Constant current |
| Operating temperature/humidity | 0~40 °C, 20~85% RH (non-condensing) |
| Storage temperature/humidity | 20~60 °C, 20~85% RH (non-condensing) |
| Cooling | Forced cooling |
| Light control mode | Variable current control; Panel key / RS232 |
| Brightness steps | 1000 (0-999) |
| Input voltage | AC100-240V 50/60Hz |
| Channels | 2 |
| Output voltage | 48V |
| Max output | 2.8A (single channel maximum current 1.4A) |
| Total power | 150W |
| Output port | dia.12 |
| External trigger voltage | DC5V~24V (current about 5.6mA) |
| Trigger delay | <50us |
| External trigger port | 1+ / 1- (CH1 external trigger input positive / negative), 2+ / 2- (CH2 external trigger input positive / negative) |
| Front panel rating label | 100-240V~ 50/60Hz 185VA |
| Dimensions (mm) | 231.7 L x 122.5 W x 147 H (body 220 L, 141 H; mounting holes 196 x 96) |
| Total output (W) | 150 |
| Shipping weight | 1.75 kg |
Applications
- Driving high-power coaxial lights (LS-HCOS series)
