Rendered illustration: the actual product may differ in appearance.
Bar lights
Bar light, 101.6 mm (LS-BAR-0204)
Model LS-BAR-0204
LED bar light for directional, low-angle or angled illumination: edges, surface texture, engraving and label reading, mounted singly or in pairs and quads. 24 V DC supply; connection: m12 quick-disconnect.
Specifications
| Model | LS-BAR-0204 |
|---|---|
| Colour | Amber (590nm) |
| Length (mm) | 101.6 |
| Width (mm) | 101.6 |
| Voltage | 24 V DC |
| Connector | M12 quick-disconnect |
| Intensity control | 0-10 V DC analog, potentiometer |
| Driver | Internal |
| Nominal size | 4 x 4 in |
| Options | Diffuser and cable types on request |
| Supply voltage (derived) | 24 V DC, derived: all 223 bar lights of this range that state a voltage are rated 24 V |
