Adjustable adapter controller, 72W, 1 channel, 1 ch, 72 W (LS-AV72-24030-1)
Model LS-AV72-24030-1
Adopt high efficiency, low loss, environmental protection line design. The product is beautiful and generous, the shell adopts high temperature flame retardant, ultrasonic welding, the use of safe and reliable. Output interference is very small, the output voltage is stable, can better extend the service life of external appliances.
Features
- Adopt high efficiency, low loss, environmental protection line design
- The product is beautiful and generous, the shell adopts high temperature flame retardant, ultrasonic welding, the use of safe and reliable
- Output interference is very small, the output voltage is stable, can better extend the service life of external appliances
- Universal visual light source output interface, can be connected to 24V LED light source, light source brightness is stable
Specifications
| Model | LS-AV72-24030-1 |
|---|---|
| Maximum output current of single channel | 3A |
| Overcurrent protection | NO |
| Over-voltage protection | NO |
| Output voltage | 24V |
| Input fluctuation range | 90V-264V 47Hz-63Hz |
| Voltage adjustment range | 9~24V |
| Output power | 72W |
| Output error | <±5% |
| Efficiency | >80% |
| Ripple | Within 100mv |
| High voltage test | >3KV 10mA 5S |
| Insulation resistance | P-S >50Mohm at 500V DC |
| Operating temperature range | 20°C-45°C, humidity 30%-85% |
| Transportation and storage environment | Temperatures 0°C-75°C, humidity 0%-95% (Top) |
| Drive type | Constant pressure (as printed) |
| Built-in power supply power | 72W |
| Number of channels | 1 |
| Connected light source type | ≤3A 24V power supply |
| Catalog page | P56 |
| Total output (W) | 72 |
| Control | analog knob (voltage adjustment, 3-digit voltage display) |
| Shipping weight | 0.50 kg |
