Cables
Power Cord, S2p (JPN) to C13 plug, 1.5 m (LS-AC-POWER-CABLES-JPN-S2P-C13-1.5M)
Model LS-AC-POWER-CABLES-JPN-S2P-C13-1.5M
Power Cord, S2p (JPN) to C13 plug, 1.5 m. The AC power cables can be used to provide AC power to the device with the power adapter, and is available in a variety of specifications.
Features
- The AC power cables can be used to provide AC power to the device with the power adapter, and is available in a variety of specifications.
Specifications
| Model | LS-AC-POWER-CABLES-JPN-S2P-C13-1.5M |
|---|---|
| End A connector | S2p (JPN) |
| End B connector | C13 plug |
| Cable diameter | 6.6 mm |
| Length | 1.5 m |
| Cable mechanical | VCTF 2X0.75mm2 |
| Jacket | PVC |
| Cable color | Black |
| Connector durability | 3, 000 cycles |
| Applicable scenario | Static scenes |
| Max. ±45° bending cycles | -- |
| Max. ±60° bending cycles | 5000 times |
| Max. ±90° bending cycles | -- |
| Max. voltage | 250 VAC |
| Max. current | 7 A |
| Working temperature | –20°C to 70°C (–4 °F to 158 °F) |
| Certification | PSE |
| Packaging | Individual package |
| Shipping weight (estimated) | 0.31 kg |
Complete the station
Drive the light from a light controller and pair it with a lens for your field of view and working distance.
Light controllers LensesSelection guideOther sizes in the Power cords and supplies series
| Model | Size | Price | Availability | |
|---|---|---|---|---|
| LS-AC-POWER-CABLES-EUR-E2P-C13-1.5 | 1.5 m | $39.00 | 3 in stock | View |
| LS-AC-POWER-CABLES-GBP-E3P-C13-1.5M | 1.5 m | $39.00 | 3 in stock | View |
| LS-AC-POWER-CABLES-IND-E3P-C13-1.5M | 1.5 m | $39.00 | 2 in stock | View |
| LS-AC-POWER-CABLES-ISR-E3P-C13-1.5M | 1.5 m | $39.00 | 4 in stock | View |
| LS-AC-POWER-CABLES-KOR-S2P-C13-1.5M | 1.5 m | $39.00 | 2 in stock | View |
| LS-AC-POWER-CABLES-USA-S3P-C13-1.5M | 1.5 m | $39.00 | 4 in stock | View |
| LS-AC-POWER-CABLES-TWN-S3P-C13-1.5M | 1.5 m | $39.00 | 4 in stock | View |
| LS-AC-POWER-CABLES-BRA-S3P-C13-1.5M | 1.5 m | $39.00 | 5 in stock | View |
| LS-AC-POWER-CABLES-ARG-S3P-C13-1.5M | 1.5 m | $39.00 | 2 in stock | View |
| LS-AC-POWER-CABLES-ITA-S3P-C13-1.5M | 1.5 m | $39.00 | 3 in stock | View |
